Shacman F3000 8x4 400hp 25m3 Dump Trucks RHD/LHD
Shacman F3000 8x4 400hp 25m3 Dump Truck incorporates key advanced technologies. Engineered for both the Chinese and international markets, it represents a new - generation high - end heavy truck. It is advanced, with a well - developed and reliable design.The reliability of the dump truck is built on years of research, development, and testing. Every component is rigorously inspected and verified to ensure it can withstand the harsh conditions of heavy - duty work. Whether it is used in construction sites, mining areas, or long - distance transportation, this dump truck can always be counted on to perform its duties efficiently and safely.
Shacman F3000 8x4 400hp 25m3 Dump Trucks RHD/LHD
Shacman F3000 8x4 400hp 25m3 Dump Trucks RHD/LHD
Shacman F3000 8x4 400hp 25m3 Dump Trucks RHD/LHD
Shacman F3000 8x4 400hp 25m3 Dump Trucks RHD/LHD
Shacman F3000 8x4 400hp 25m3 Dump Trucks RHD/LHD
Shacman F3000 8x4 400hp 25m3 Dump Trucks RHD/LHD Specification
Main Spec.:
1、AC or warm air are optional according to your requirement.
2、400HP, 340HP, 380HP, 430HP are optional;
3、10JSD180 or 12JSD200T gear box are optional;
4、30 cubic yard, 25CBM, 30CBM are optional;
5、Can make different thickness and different shape of cargo body.
Model | SX3315DU366 Heavy Duty Type |
Traction type | 8X4 |
Driving type | RHD |
Driver's cab | F3000 flat roof, air conditioner, hydraulic driver seat, 4-point hydraulic suspension cabin |
Dimension | Wheel base(mm): 1800+3575+1400 |
Overall size(mm): 10250x2490x3450mm | |
Engine | Brand: Weichai |
Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling | |
Engine model: WP12.400E201 Euro II | |
Maximum output: 400HP | |
Rated speed: 1900rpm | |
Max torque: 1920N.m/1000-1400rpm | |
Number of cylinder:6 | |
Displacement: 11.596L | |
Clutch | 430mm |
Transmission | 10JSD180+QH50 |
Front axle | MAN 9.5T |
Rear axle | MAN 16T double reduction driving axle, inter-wheel differential and differential lock Ratio: 4.769 |
Tyre | 12.00R20 Radial tyre (10+1 pcs) |
Electrics | Operating voltage: 24V, negative grounded |
Weight | Curb weight: 14600kg |
Loading capacity: 40000kg | |
Performance | Maximum driving speed: 80km/h |
Cargo Box | |
Box inner size | 7400x2300x1500mm |
Thickness | Floor plate 8mm and side 6mm |
Lifting system | Front lifting system |
Applications:
√ Construction sites：Transport construction materials and clear construction waste
√ Mining operations：Carry ores and waste rocks
√ Road engineering：Transport materials for road construction and maintenance
√ Agricultural field：Move agricultural products, fertilizers and soil
√ Municipal engineering：Transport earthwork and urban garbage
