Cab | MAN F2000 Cab Single bed Air conditioner |
Dimension(Lx W xH)(mm) | 9550×2500×3530mm |
Total mass(kg) | |
Kerb mass(kg) | 10900kg |
Rated mass(kg) | 13970kg |
Approach / departure angel | 16/17 |
Front/rear suspension(mm) | 1525/2400 |
Max. gradeability (%) | 25 |
Engine brand | Weichai Engine |
Engine model | WP10.290E32,290hp |
Rated output power | 213kw |
Torque(N.m r. p. m) | 1160N.m/1200-1600rpm |
Rated speed(rpm) | 2200rpm |
Emission Standard | E-II |
Displacement(L) | 9.726L |
Driving type | 6×4 |
Axle number | 3 |
Wheel base(mm) | 4300+1400mm |
Clutch | φ430 diaphragm spring |
Gearbox | FAST 9JS135,9 Forward&1 Reverse,Manual |
PTO | QH50 |
Front axle | 7.5T MAN 7500kg |
Rear axle | 13T STR 2×13000kg |
Ratio | 4.8 |
Steering | ZF technology left-hand drive(LHD) |
Brake system | WABCO ABS(Four channel) |
Type | 12R22.5,10+1pc |
Tank capacity(L) | 400L |
Max. speed (km/h) | 90km/h |
Color | Optional |
Tank volume | 20000L |
Water tank configuration | Pump,Front spray,Rear sprinkle,Rear spray,Back work platform… |
